基于A(yíng)NSYS客車驅動橋齒輪副的應力分析

打開文本圖片集

中圖分類號：U463.218 文獻標識碼：A 文章編號：1003-8639(2025)06-0114-03

Stress AnalysisofBusDrive AxleGear Pairs Basedon ANSYs

ShengPaipai，LiuYifan，WangSen

(Shangqiu Institute of Technology，School of Mechanical Engineering，Shangqiu 476Ooo，China）

【Abstract】Basedon the design requirements of thebus driveaxle，this article elaborates on the current technical statusanddevelopmenttrendof thedriveaxle，anduses the finite element analysis tolANSYSWorkbench to conduct mechanicalanalysisonthegear pairs inthedrive axle，mainlyanalyzingthe stressclouddiagrams of thehighandlow speed gear pairs underdiferent working conditions.The analysis results show thatthe maximum contactstress value of the high-speedgear pairis169.46MPaandthatof thelow-speed gearpairis 600.69MPa.Referring totherequirements ofthedriveaxledesigncode，itisless thantheyieldlimitofthematerial.Then，basedontherequirementsofthedrive axledesigncode，verifythat the designandmaterialsof the driveaxlearereasonable toensurethereliableuse of the drive axle.

【Key words】 ANSYS；drive axle；gear pair；stress analysis

0 引言

中型客車專為城市與鄉村之間的交通運輸而設計。（剩余5245字）
