基于離散矢量模型的微電機轉子二次去重動平衡研究

打開文本圖片集

關鍵詞：轉子動平衡；微電機；切削去重不平衡校正方法；離散矢量模型；初始不平衡量 中圖分類號：O347.6；TM38 文獻標志碼：A DOI：10.16385/j.cnki.issn.1004-4523.202306048

Two-steps weight-removing for dynamic balancing of micromotor rotor basedondiscretevectormodel

JIANG Dong，XUE Zimin，LU Zhenrong，LI Mengxuan， CHEN Weiyu，HANG Xiaochen （SchoolofMechanical and Electronic Engineering，Nanjing Forestry University，Nanjing 2loo37，China）

Abstract：Amillngunbalance corection methodbasedonadisrete vector model is proposed toaddress theissueofpoorperfor manceoftraditionaldynamicbalancing methodswhentheinitialunbalanceofthemicromotorrotorislrge.Adiscretevectormodelis establisdbasedontheparametersofthemillngcuterandotorndthecorespondingrelationshipbtweentheequvalent cuting massandcutingdepthundersecond tiecuttingisobtainedbyintegratingthediscretepointsoftheedgecurve.Bycompar ingwiththe3Dmodelsimulationdata，itisverifiedthathedviationrateofthemodelislow.Experimentalverificationshowsthat when the initial unbalance on one side of the rotor exceeds 100mg ，a total weight removal rate of over 90% can be achieved，and the equivalent mass of the remaining unbalance on one side can be controlled below 10mg .All rotors meet the Gl accuracy level. This indicates thatthisproposed methodcanimprovethedynamicbalanceaccuracyofthe micromotorrotorwhentheinitialunbalance of the micro motor rotor is large.

Keywords：rotordynamicbalancing；micromotor;milingunbalancecorrectionmethod;disretevectormodel;initialunbalance

微電機作為基礎性的電子器件被廣泛應用于各種機電設備中。（剩余12815字）
