新型抗剪性螺栓球節點力學性能研究

打開文本圖片集

中圖分類號：TU391 文獻標志碼：A 文章編號：1005-8249（2025）02-0110-07

DOI：10.19860/j.cnki.issn1005-8249.2025.02.019

Abstract：Inordertodevelopthegridstructureof theownerlesspurlinboltballjint，anewshearboltballjoint wasdesiged， andtheballjointsof three newbolts with diferentbolt diametersof M24，M27and M3Owere testedthroughthecompreson， tensionand shear tests，andtheircomponentsandoverallmechanical properties were studied.Theresultsshowthat when the jointiscompressed，thenew node sleeveis morecompressivethan theordinary joint，andthenew nodebolt bears acertain force.When tensioned，themechanicalvariationlawofeachcomponentof thetwo joints isconsistent.Whensubjected to bendingshear，theshearresistanceof thenewjointis improvedtoacertain extent，theultimatebending momentsof thenew M24，M27 and M30 joints are increased by 2 % ， 6 % and 13 % respectively. The test results are compared with the simulation results，and the maximum error is not more than about 10 % ：

Keywords：newboltballnodes；nodalstrain；nodal moments；mechanical tests；finiteelementanalysis；comparativeanalysi

0 引言

螺栓球網架結構因結構穩固、施工便捷、外型美觀而被廣泛應用。（剩余6067字）
