地?zé)嵩醋饔孟露軜?gòu)隧道地震響應研究

打開文本圖片集

關鍵詞：巖土工程；盾構隧道；地?zé)嵩?；地震；?shù)值模擬；有限元中圖分類號：TU435;[U25] 文獻標志碼：A本文引用格式：，肖穎，梁壽，等.地?zé)嵩醋饔孟露軜?gòu)隧道地震響應研究[J].華東交通大學學報，2025，42（2）：87-94.

Study on Seismic Response of Shield Tunnel Under the Action of Geothermal Source

Zhang Xuan’，Xiao Ying'，Liang Shou'， Yu Jiake2，WangRui3，HuLiming3

（1.CCCC-SHEB Third Engineering Co.，Ltd.，Xi'an710018，China;2.Zhejiang Huadong Geotechnical

Investigation & Design Institute Co.，Ltd.，Hangzhou 310o13， China; 3.School ofCivil Engineering， TsinghuaUniversity，Beijing10oo84，China）

Abstract：To investigate the seismic safety performance of shield tunnels under geothermal source effects，based on Xi'an Metro Line 10 project， finite element numerical simulation was adopted to reproduce the seismic response of shield tunnels under geothermal sources，and the influence of diferent relative positions between geothermal sources and the tunnel was analyzed.The results show that geothermal sources significantly amplify the stress levels in tunnel segments near the heat source while reducing the joint opening displacements in these areas，with minimal impact on sections far from the heat source.The distance between the heat source and the tunnelaffcts the stress levels in tunnel segments but has little influence on joint opening displacements.Geothermal sources significantly afect joint opening displacements and stress in shield tunnels near the heat source but have negligible impact on parameters such as acceleration and tilting angles.The research can provide reference for the design of similar working condition in the future.

KeyWords： geotechnical engineering; shield tunnel; geothermal source; earthquake; numerical simulation;finite

element

Citation format： ZHANG X，XIAO Y，LIANG S，et al.Study onseismic response of shield tunnel under the action of geothermal source[J].Journal of East China Jiaotong University，2025，42（2）： 87-94.

盾構隧道作為城市軌道交通中的重要結構，一般是由鋼筋混凝土管片和接頭螺栓連接而成，其抗震安全受到廣泛關注。（剩余8527字）
