輪軌接觸力無線遙測系統的研究與開發

打開文本圖片集

中圖分類號：TB9；U270.7；TP368.1 文獻標志碼：A 文章編號：1674-5124（2025）06-0123-09

引用格式：唐家明，方聰聰.輪軌接觸力無線遙測系統的研究與開發[J].中國測試，2025，51（6）：123-131.TANGJiaming，F(xiàn)ANG Congcong.Researchanddevelopmentofwirelesstelemetrysystemforwhel-railcontactfore[J].China Measurement&Test，025，

Research and development of wireless telemetry system for wheel-rail contact force

TANG Jiaming1 23，， FANG Congcong1 1，2，3

（1. Key Laboratory of Traffc Safety on Track，School of Traffic & Transportation Engineering， Central South

University， Changsha 410075，China; 2.Joint International Research Laboratory ofKeyTechnology for RailTraffic

Safety，Central SouthUniversityChangsha41O75，China;3.National&LocalJointEngineering Research Centerof Safety Technology for Rail Vehicle， Central South University， Changsha 41o075， China）

Abstract： The continuous，real-timeand accurate measurement of wheel-rail contact force is an important means to realize the monitoring and evaluation of vehicle running safety，stability and comfort. In this paper， basedon the finite element method，the whel-rail contact modelisestablished，and the mathematical relationship between the rim strain and the wheel-rail contact force is obtained. Based on the strain gauge Wheatstone bridge and Bluetooth wireless communication technology， a wireless telemetry system for wheelrail force is designedand developed.The system includes the hardware and software ofthe lowercomputerand the data acquisition and analysis software of the upper computer. The feasibility and accuracy of the telemetry system are verified by the whel-rail force measurement of the wheel hub strain measurement and the collision sled rim strain measurement. Compared with the commonly used force measuring whelset method， it does not need to process a special wheelset，and can realize the in-situ measurement of whee-rail force， which has the advantages of low cost and convenient implementation.

Keywords： wheel-rail contact; strain; finite element analysis; wireless communication

0 引言

輪軌接觸力是影響列車動力學性能、安全與平穩性的關鍵因素。（剩余10497字）
