防爆墻對某廠區LPG 管網泄漏-爆炸事故后果的影響

打開文本圖片集

中圖分類號：X932；0389 文獻標志碼：A 文章編號：1672-9315（2025）04-0716-10DOI：10.13800/j. cnki. xakjdxxb. 2025.0408

Effects of explosion-proof wall on the leakage-explosion accident of LPG pipe network in a factory

WANG Qiuhong1，DU Sunwei1， DONG Guoqiang2， LUO Zhenmin'， ZHANG Mingguang3， XUE Yunfan'

（1.CollegeofSafetySienceandEngineeing，Xi'an UniversityofScienceandTechnology，Xi'ano54，China; 2. Institute for Hygiene of Ordnance Industry， Xi' an 71oo65， China; 3.College of Safety Science and Engineering，Nanjing Technology University，Nanjing21ooo9，China）

Abstract： A quantitative study was conducted using FLACS software to assess the mitigation effects of explosion hazards caused by LPG pipeline leakage in a petrochemical plant in Shaanxi， with a focus on reducing explosion risks by installing blast walls between the facility area and the offce-living zone. The study investigated the blast mitigation performance of the blast walls by analyzing their position D （the distance between the blast wall and the leftmost edge of the ofice-living zone），height H，and thickness d.The results demonstrated that the farther the blast wallis from the explosion source and the closer it is to the office-living zone，the better the protective effect on the office-living zone.For a 24m high building within the ofice-living zone of the petrochemical plant，when the blast wall was positioned 5 m from the office-living zone withheights of 3 m and 11m ，the corresponding reductions in overpressure behind the wall were 52.20% and 70.33% ，respectively.For blast wall thicknesses d of 0.1，0.3，0.5 m and 0.7m ，the corresponding overpressure reductions behind the wall were 68.29% ， 67. 44% ， 66.80% ，and 66.41% ，respectively. For rigid structural blast walls，the height of the wall has a more significant impact on reducing overpressure behind the wall compared to its thickness， indicating that the design of blast wall height ismore critical for explosion prevention and mitigation.The simulation results provide a reference for proactive hazard protection in the petrochemical plant.

Key words： LPG; leakage diffusion; explosion risk analysis; location of explosion-proof wal; height of the explosion-proof wall; thickness of the explosion-proof wall

0 引言

隨著石化行業的蓬勃發展，液化石油氣（LiquifiedPetroleumGas，簡稱LPG）作為一種化工原料，具有易存儲、運輸便利、高熱值等優勢，在工業生產和日常生活中被廣泛應用[1-2]。（剩余14286字）
